Metallurgical Microscope MMMM-A101 with 1000x magnification enables detailed metallurgical structure analysis. Built with trinocular viewing head, allowing simultaneous visual and digital observations. Its infinity-corrected optical system supports extra-wide field eyepieces and plan achromatic objectives. Equipped with quintuple nosepiece and refined coaxial focusing system for smooth operation. Our microscope provides advanced illumination with powerful halogen lamp and compatibility with camera systems.
Catalog| Viewing Head | Hinged type trinocular head |
| Eyepiece | EW10X/22 |
| Objectives |
5X/0.12/∞/- WD 15.5mm 10X/0.25/∞/-（BF/DF）WD 10.0mm 20X/0.40/∞/0（BF/DF）WD 4.30mm 50X/0.75/∞/0 WD 0.32mm 100X/0.80/∞/0 WD 2.00mm |
| Nosepiece | Quintuple Nosepiece |
| Stage Size | 300mm×268mm |
| Movement Range | 250mm×200mm |
| Focusing Range | 24mm |
| Illumination | Halogen lamp 24V/100W |
| Filter |
Blue Green Yellow Ground glass |
Adjustable brightness
Large stage with wide moving range
Excellent optical quality
LWD high magnification objective
Low and pre-position control knob
Metallurgical Microscope MMMM-A101 is employed to study metals, ceramics, composites, plastics, polymers, food, porous materials, cosmetics, particles, glass, films, textiles, and fibers. It supports advanced imaging needs in laboratories industries and research institutions.
